Featuring an assembly of reusable polyester cartridge elements with precision-engineered cores, SwimClear™ multi-element cartridge filters provide heavy-duty dirt-holding capacity and extra-long filter cycles. In fact, as the industry's largest filter, the C7030 model offers the longest time possible between cleanings. SwimClear filters' top manifold configuration boasts industry-leading hydraulic performance, facilitating maximum flow through all cartridge elements for superior water clarity and increased energy savings.

  • Top manifold configuration provides excellent filtration and hydraulic performance for reduced cost of operation

  • Cleanable cartridge elements eliminate the requirement for backwashing

  • Filter tanks are made from the most durable materials to meet the demands of the toughest applications and environmental conditions

  • High capacity, rapid release manual air relief valve bleeds air with a quick quarter turn of the lever

  • Heavy-duty, tamper-proof, one piece flange clamp securely fastens tank top and bottom and allows quick access to all internal components


SPECIFICATIONS AND DIMENSIONS
Filter TypeCartridge elements: 225, 325, 425, and 525 ft2 (4 cartridge elements), 700 ft 2 (8 cartridge elements)
Filter TankHigh-strength, injection-molded durable glass reinforced copolymer
Filter ElementReinforced polyester
Performance Range84 to 150 GPM, 318 to 568 LPM
DimensionsC2030 – 24" W x 32½" H
C3030 – 24" W x 34½" H
C4030 – 24" W x 40½" H
C5030 – 24" W x 46½" H
C7030 – 24" W x 52½" H
